Brickwork estimates come down to one idea: a wall is a volume, and each brick with its share of mortar takes up a known part of that volume.
Brick sizes in India
| Brick | Actual size (mm) | Size with 10 mm joint (mm) | Bricks per m³ |
|---|---|---|---|
| Modular | 190 × 90 × 90 | 200 × 100 × 100 | 500 |
| Conventional (9" × 4½" × 3") | 230 × 110 × 75 | 240 × 120 × 85 | ≈ 408 |
Modular sizes are specified in IS 1077. Conventional bricks are still widely used; measure the bricks you are actually buying, because sizes vary between kilns.
Step 1: wall volume
Deduct doors and windows. A 9-inch wall is 230 mm (0.23 m) thick; a 4½-inch wall is 115 mm.
Step 2: number of bricks
Step 3: mortar and materials
Dry mortar = wet mortar × 1.33
Cement (m³) = dry ÷ (1 + n) · Sand (m³) = dry × n ÷ (1 + n)
Here n is the sand part of a 1 : n mortar. The 1.33 factor (you will also see about 1.27) allows for the bulking of dry sand and cement. Cement converts to bags at 1,440 kg/m³ and 50 kg per bag.
WORKED EXAMPLE · 9-INCH WALL, CONVENTIONAL BRICK, 1:6 MORTAR
Wall 20 × 10 ft, no openings: 6.096 × 3.048 × 0.23 = 4.274 m³One brick with joint: 0.24 × 0.12 × 0.085 = 0.002448 m³
Bricks = 4.274 ÷ 0.002448 = 1,746; with 5% wastage and rounded up to whole bricks, 1,834
Solid brick volume = 1,746 × 0.23 × 0.11 × 0.075 = 3.313 m³
Wet mortar = 4.274 − 3.313 = 0.961 m³ → dry = 0.961 × 1.33 = 1.279 m³
Cement = 1.279 ÷ 7 = 0.183 m³ → 5.3 bags (buy 6)
Sand = 1.279 × 6 ÷ 7 = 1.096 m³ (≈ 39 cft)
Practical allowances
- Breakage and cutting: 5% is a common allowance on bricks; more for poor-quality bricks or complicated walls.
- Mortar mix: 1:6 is common for 9-inch walls and 1:4 for 4½-inch partition walls, but always follow the project specification.
- Frogs: bricks with a frog (indent) take extra mortar if laid frog up and filled.
